Accurate real-time and historical data, enabling a comprehensive evaluation of system performance.
Compatible with SOLARMAN data logger, ensuring simple configuration and lower O&M cost.
Powerful platform, providing visualized meteorological data.
Real-time alerts with timely notification, ensuring fast troubleshoot
Standard sensors for general demands (High accuracy sensor for project with high demands).
| Product Model | WP-2S |
| Irradiance (Sub-reference Level) | ISO 9060:1990 (Sub-reference Level) Sensitivity: 7～14μV/W/m2 Instability (Year): <0.5% Measuring Range: 0～4000W/m2 Spectral Range: 270～3000μm Zero Offset (No ventilation) (a) Thermal Irradiance (200W/m2): <7W/m2 (b) Temperature Variation (5K/h): <2W/m2 Nonlinear: ＜0.2% Directional Response (80°, 1000W/m2 at max.): <10W/m2 Spectral Selectivity (350～1500nm): <1% Tilt Response (0°-90°, 1000W/m2): <0.2% Temperature Response (-10℃～+40℃): <1% Visual Angle: 180° |
| Irradiance (Level 1) | Sensitivity: 7～14μV/W/m2 Instability (Year): ±2% Measuring Range: 0～2000W/m2 Cosine (Deviation between solar altitude angle 10° in sunny day and ideal value ): ≤±2% Spectral Range: 0.28～3.0μm Temperature Characteristic (-20℃～+40℃): ±2% Nonlinear: ±2% Visual Angle: 180° Measurement Accuracy: 2% |
| Irradiance (Level 2) | Sensitivity: 7～14μV/W/m2 Instability (Year): <2% Measuring Range: 0～2000W/m2 Cosine (Deviation between solar altitude angle 10° in sunny day and ideal value ): ≤±5% Spectral Range: 0.28～3.0μm Temperature Characteristic (-20℃～+40℃): ±5% Nonlinear: ±5% Visual Angle: 180° Measurement Accuracy: 5% |
| Ambient Temperature | Measuring Range: -50.0℃～+80.0℃ Resolution: 0.1℃ Accuracy: ±0.1℃ Working Environment: Temperature -40℃～+80℃ Humidity ≤100%RH |
| Ambient Humidity | Measuring Range: 0.0～100.0%RH Resolution: 0.1%RH Accuracy: ±2% (≤80%), ±5% (>80%) Working Environment: Temperature -40℃～+80℃ Humidity ≤100%RH |
| Wind Direction | Measuring Range: 0～360° Resolution: 3° Accuracy: ±3° Startup Wind Speed: ≤0.5m/s Working Environment: Temperature -40℃～+80℃ Humidity ≤100%RH |
| Wind Speed | Measuring Range: 0～70m/s Resolution: 0.1m/s Accuracy: ±(0.3+0.03V)m/s Startup Wind Speed: ≤0.5m/s Working Environment: Temperature -40℃～+80℃ Humidity ≤100%RH |
| Module Temperature | Measuring Range: -50℃～+80℃ Resolution: 0.1℃ Accuracy: ±0.1℃ Working Environment: Temperature -40℃～+80℃ Humidity ≤100%RH |
| Height | 1.5m |
| Power Supply&Communication Junction Box | Power: AC 230V, COM: RS485 |
| IP Grade | IP65 |
